Description
- Plastic Base
| Type | Rolling Lobe |
| Airspring Brand | Automann Phoenix |
| Automann Bellows # | 1DK23K |
| Firestone Bellows# | 1T15M-6 |
| Contitech Bellows# | 9 10-16 |
| Load (Lbs) @80 PSI | 5500 |
| Load (Lbs) @100 PSI | 7000 |
| Natural Freq. (CPM) | 70 |
| Design Height (In) | 13.50 |
| Bottom Plate Type | Plastic |
| Top Plate Hole/Stud Qty | 2 |
| Top Plate Dia. (A) | 9.00 |
| Top Plate C to C Dia. (B) | 5.50 |
| Bottom Plate Hole/Stud Qty | 4 |
| Bottom Plate Dia. (C) | 10.28 |
| Bottom Plate C to C Dia. (D) | 7.87" |
| Bottom Part # | BS08133 |
| Bumper | Yes |
| Bracket | N/A |
| Min. Height | 7.90 |
| Max. Height | 21.50 |
| Max. Dia. | 12.60 |
