Description
Why Choose Donaldson DuraLite™ Air Cleaners?
Rugged, lightweight, self-supporting, and completely disposable combination air cleaner and filter.
• Function well under severe pulsation conditions, particularly two- and three-cylinder engines.
• Vibration-resistant media is secured into molded housings of rugged ABS plastic—so they don’t fall apart as other designs might.
• Easy to install, durable, and reliable.
• Completely disposable — acceptable for normal trash pick-up (DuraLite should not be incinerated).
Attributes
| Outlet Diameter | 3.00 inch (76.2 mm) |
| Body Diameter Maximum | 8.50 inch (215.9 mm) |
| Body Length | 9.50 inch (241.3 mm) |
| Efficiency Test Std | ISO 5011 |
| Rated Flow LR | 170 cfm (4.8 m³/min) |
| Rated Flow MR | 205 cfm (5.8 m³/min) |
| Rated Flow HR | 244 cfm (6.9 m³/min) |
| Restriction LR | 4.02 inch H2O (102 mm H2O) |
| Restriction MR | 5.98 inch H2O (152 mm H2O) |
| Restriction HR | 7.99 inch H2O (203 mm H2O) |
| Family | ECC |
| Type | Primary |
| Style | Round |
| Brand | DuraLite™ |
| Media Type | Cellulose |
| CROSS REFERENCES | |
| Manufacturer Name | Manufacturer Part Number |
| CASE/CASE IH | NX14210074 |
| CUMMINS | 10000390 |
| NAPA | 6314 |
| SUPERIOR COMPRESSOR | 15090454 |
Warranty Information
Manufacturer's Waranty
