Description
LED PERFORMANCE IN A RUGGED PACKAGE PROVIDES MOUNTING FLEXIBILITY, SMALL SIZE, AND POWERFUL PERFORMANCE
FEATURES & BENEFITS
• 10 x10cm housing with a reduced depth of only 75 mm
• Die-cast aluminum housing and stainless steel mounting bracket for toughest environmental conditions
• Scratch resistant and UV-proof hard coated polycarbonate lens
• Sealed lamp resists particle and water intrusion which meet IP69K
• Includes heat management and transient protection technology for enhanced LED life
Plug connector: Deutsch DT
Mounting: Stud with adjustable ball socket
Beam Pattern: Close Range
ELECTRICAL PROPERTIES
Input voltage: 9 V - 32 V
Power draw: 26 W
Electrical protection: Reverse polarity, ESD, excess voltage
Operating temperature
range -40°C to +50°C / -40°F to 122°F
Reverse polarity protection ✓
Overheat protection ✓
ESD, overvoltage and
transient protection ✓
Materials
Lens: Scratch and UV resistant hard coated polycarbonate
Housing: Aluminum powder-coated
Color Black
IP Code IP69K
Maximum storage temperature -55°C to +110°C / -67°F to 230°F
Impact and shock resistance 50G
Vibration resistance 5G (5-500Hz)
