SuperNova® Thin-Line LED Clearance Marker Lights

Grote's SuperNova® Thin-Line LED Clearance Marker Lights are designed to fit a wide variety of narrow rails and channels. Each is constructed with encapsulant potting, providing total circuit board protection and increasing each light's longevity. Our Thin-Line Clearance Markers are available with red and yellow lenses, multiple body colors and utilize Grote's UBS® Double-Seal pigtails for maximum defense against corrosion.

Features & benefits

• Sealed marker lamp
• Encapsulant potting for total circuit-board protection
• Thin-Line design fits narrow rails and channels
• Uses UBS double-seal pigtail for maximum protection against corrosion

Technical specifications

• Material: Polycarbonate Lens, Polycarbonate Housing
• Color: Amber
• Lens Color: Amber
• Housing Color: Amber
• Amperage: .07A
• Mounting Type: Screw
• Size: 3"
• Regulations: FMVSS 108
• Functions: P2
• VMRS: 034-004-253
• Product Type: Clearance Marker
• Style: Thin-Line
• Product Line: SuperNova®
• Shape: Rectangular
• Warranty: 10 Years
