Product Description
Oval LED S/T/T Lamp, Grommet Mount- Red (60 Series Clone)
FEATURES & BENEFITS
- Encapsulant potting for total circuit board protection
- Meets specifications for vertical and horizontal mounting
- Pin connection system uses tin-plated, solid-brass terminals
- Male pin termination for maximum moisture and corrosion protection
TECHNICAL SPECIFICATIONS
- Material: ABS/Acrylic
- FMVSS: I, P2, S, T
- Color: Red
- Voltage Amp: 12V /0.28A (I,S)/0.2A(T)
REPLACEMENTS / ACCESSORIES
| Type | Part Number |
|---|---|
| Bracket | 42152, 43220, 43952, 43100, 42153,43222, 43362, 43223, 43723 |
| Grommet | 92420, 92720 |
| Pigtail | 66814, 66830, 67006, 66813, 66823,66836 |
| Pigtail BU 2-Wire | 67013, 66846, 67016, 66842 |
| Pigtail STT 3-Wire | 66815, 66816, 66841, 66845, 67002,67005 |
Product Videos
Custom Field
SIZE 6"
STYLE LED
APPLICATION STOP/TAIL/TURN
COLOR RED
SHAPE OVAL
MOUNT GROMMET
PLUG 3 PIN ROUND
