Description
Features & benefits
- Receptacle is overmolded
- Two-hole mount, solid pin socket
- Heavy bosses for extra rigidity
- Mounting holes slotted for universal fit
- No-rust, die-cast zinc, brass pins
- Barrel slanted to drain moisture
- 2 male terminals for grounding
Technical specifications
- Connector Side Two: UBS 7-Way Female/Single eyelet
- Wire Material: GPT
- Connector Quantity: 4
- Connector Side One: Nose box plug (Solid-pin)
- Wire Gauge: 1-10 GA, 6-12 GA
- Connection Type: Nose box plug (Solid-pin), UBS 7-Way Female/Single Eyelet
- Length: 14"
- Wire Length: 8"
- Pack Quantity: Bulk
- Product Type: Harness
- # of Wires: 7
- Style: Main Harness
- Product Line: Ultra-Blue-Seal®
- Standards: J560
- Regulations: FMVSS 108
- VMRS: 034-003-034
- Material: Die-cast Zinc
- Product Type: Receptacle
- Terminals: Solid Pin
