Grote G5092 Hi Count LED Box Combo Lamp- LH w/ License Window- 3 Stud Mount, 3 Wire

Product Description

Grote G5092 Hi Count LED Box Combo Lamp- LH w/ License Window- 3 Stud Mount, 3 Wire

Technical specifications

• Material: Acrylic Lens, Polycarbonate Housing, Polycarbonate Lens
• Color: Red, White
• Lens Color: Red/Clear
• Housing Color: Black
• Voltage: 12V
• Amperage: .12A-.34A
• Mounting Type: Stud
• Connection Type: Blunt Cut
• Regulations: FMVSS 108
• Functions: S, T, I, L, A, R(2)
• VMRS: 034-002-022
• Product Type: Stop Tail Turn
• Shape: Square
• Bulk Pack #G5092-3: 0

Features & benefits

• Includes reflex reflector
• Directly replaces Jeep® Wrangler® lamps through 2006
• 16 stop/tail/turn diodes, 22 backup diodes and 4 license diodes
• Potting protects against vibration and corrosion
• Circuit-board protection is compatible with existing flasher technology
• All functions utilize LED technology
• Mounting hardware and instructions for easy installation/retrofit
• 3 stud mounting design incorporates ground function
• Gasket between lens and housing protects against moisture intrusion
