Grote G5202 Hi Count LED Box Combo Lamp- RH w/ Marker- 3 Stud Mount, 3 Wire
Technical specifications
- Material: Acrylic Lens, Polycarbonate Housing
- Color: Red
- Lens Color: Red
- Housing Color: Black
- Voltage: 12V
- Amperage: .06A-1.4A
- Mounting Type: Bracket
- Connection Type: Blunt Cut
- Regulations: FMVSS 108
- Functions: S, T, I, A, R(2)
- VMRS: 034-002-013
- Product Type: Stop Tail Turn
- # of Wires: 3
- Shape: Square
- Bulk Pack #G5202-3: 1
Features & benefits
- Includes reflex reflector
- Directly replaces Jeep® Wrangler® lamps through 2006
- 16 stop/tail/turn diodes, 22 backup diodes and 4 license diodes
- Potting protects against vibration and corrosion
- Circuit-board protection is compatible with existing flasher technology
- All functions utilize LED technology
- Mounting hardware and instructions for easy installation/retrofit
- 3 stud mounting design incorporates ground function
- Gasket between lens and housing protects against moisture intrusion
