Product Description
The only professional-grade light strips on the market rated for outdoor use. Grote’s XTL LED light kit includes everything you need to put light where you want it.
Unaffected by dust or vibration, XTL LED light strips are light weight, concussion- and abrasion-resistant accent lighting tough enough for any tractor trailer. Made in the USA, these waterproof, chemical-resistant, high-output LEDs are designed to survive whatever the elements and the highway can throw at them.
Kit Contents
LED Strips
Six amber XTL LED light strips in three different lengths:
- 71.8" x 2 (F21005-061-19-220)
- 30.23" x 2 (F21005-061-08-220)
- 22.67" x 2 (F21005-061-06-220)
Installation Accessories
- Flex tubing (2 Rolls of 83-8003 1/4" x 50' Split Flex)
- Two spools of 18-gauge wire (1 black x 100' 87-9002, 1 white x 100' 87-9007)
- Nylon cable ties (25 x 7.6" Black 85-6019)
- Pack of Shrink Butt Connectors (22-18 Gauge x 15pc 84-2929)
SPECIFICATIONS
- Made in the USA LED Light Strip
- Light weight
- Less than 1mm thick and bendable to a .5" radius
- Concussion and abrasion resistant
- Comes with 3M® VHB tape for long-term (10 year plus) adhesion
- Color: Yellow
- Ingress Protection: SAE J575 sec. 4.3, IP69K, IP67
- Product Line: XTL®
- Amperage: .51A
- Product Type: Light Strip
- Voltage: 12V
- Warranty: 1 Year
- Mounting Type: 3M Tape
- Connection Type: Blunt Cut
Frequently Asked Questions
Can the XTL light strips be cut to fit?
XTL light strips feature a printed circuit board that will not function if cut. Plan your placement before installation and position the light strips for best effect.
Can the XTL Truck Kits be ordered in different colors?
Currently, the kits are only available in amber.
Are different sizes available other than what is in the XTL HD Ground FX kit?
The strips in the XTL HD Ground FX kit are all standard lengths of 23", 30", and 72”. These can be positioned to form many different patterns and lighting configurations.
Do you have a specific XTL HD Ground FX kit for my make and model?
These kits are designed for a universal fit. The light strips can be creatively positioned to effectively accent the lines of most trucks.
Can the strips in the XTL HD Ground FX kit be moved between vehicles if I have more than one?
The tape in the XTL HD Ground FX kit features a durable 3M adhesive meant to endure years of harsh outdoor conditions and is not meant to be removed and re-installed on other equipment.
