Description
NOTE: Due to size restrictions, spoke wheels are only available for pickup or via Truck Freight.
| Spoke Wheel Specifications: | |
| Finished Weight: | 115 |
| Spoke Wheel Capacity (lbs): | 11500 |
| Number of Spokes: | 6 |
| Spoke Wheel Size: | 22 |
| Rim Size: | 8.0 Maximum |
| Axle Group 1: | R21 |
| Axle Group 2: | |
| Outer Bearing Cup: | 572 |
| Outer Bearing Cone: | 580 |
| Inner Bearing Cup: | 592A |
| Inner Bearing Cone: | 594A |
| Bearing Cup Spacing: | 4.31 |
| A-Drive Stud/Hub Cap Bolt Circle: | 7 |
| B-Drive Stud/Hub Cap Hole Pattern: | (8) .62-11 |
| C-No of Rim Studs: | 6 |
| Rim Stud Size: | 0.75 |
| D-No of Drum/Rotor Bolts: | 6 |
| Drum/Rotor Bolt Size: | 0.75 |
| E-Spoke Offset: | -1.25 |
| F-Drum/Rotor Mount Offset: | -0.22 |
| G-Drum/Rotor Pilot Diameter: | 11.25 |
| H-Drum/Rotor Bolt Circle: | 12.75 |
| I-Seal Bore Diameter: | 6.3 |
| J-Overall Length: | 9.76 |
| K-Spoke Length: | 6.81 |
