Description
Product Attributes
| Center Hole Diameter | 5.5 in |
| Center Hole Diameter | 139.7 mm |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.465 in |
| Discard Thickness | 37.2 mm |
| Mounting Bolt Hole Circle Diameter | 7.25 in |
| Mounting Bolt Hole Circle Diameter | 184.15 mm |
| Mounting Bolt Hole Diameter | 0.66 in |
| Mounting Bolt Hole Diameter | 16.75 mm |
| Mounting Bolt Hole Quantity | 10 |
| Nominal Thickness | 1.535 in |
| Nominal Thickness | 39 mm |
| Outside Diameter | 13.745 in |
| Outside Diameter | 349.1 mm |
| Overall Height | 4.365 in |
| Overall Height | 110.85 mm |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 10 |
Vehicle Linkages
-
Car/Truck
-
Chevrolet
- G30: 1992 - 1993
- P30: 1975 - 1996
- P30 Van: 1974
-
GMC
- G3500: 1992 - 1993
- P35: 1975 - 1978
- P3500: 1979 - 1996
-
Workhorse
- P30: 2000
-
-
Medium/Heavy Truck
-
Chevrolet
- C3500HD: 1991 - 1994
-
GMC
- C3500HD: 1991 - 1994
-
Workhorse
- P32: 1999 - 2005
- P42: 1999 - 2005
-
Workhorse Custom Chassis
- P32: 1999 - 2007
- P42: 1999 - 2005
-
Warranty Information
Manufacturer's Waranty
