Description
Product Attributes
| Center Hole Diameter | 3.55 in |
| Center Hole Diameter | 90.15 mm |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | No |
| Discard Thickness | 0.965 in |
| Discard Thickness | 24.5 mm |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 5.315 in |
| Mounting Bolt Hole Circle Diameter | 135 mm |
| Mounting Bolt Hole Diameter | 0.588 in |
| Mounting Bolt Hole Diameter | 14.95 mm |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.025 in |
| Nominal Thickness | 26.05 mm |
| Outside Diameter | 12.12 in |
| Outside Diameter | 307.85 mm |
| Overall Height | 2.045 in |
| Overall Height | 51.95 mm |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
Warranty Information
Manufacturer's Waranty
