Description
Product Attributes
| Center Hole Diameter | 4.86 in |
| Center Hole Diameter | 123.45 mm |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | No |
| Discard Thickness | 1.429 in |
| Discard Thickness | 36.3 mm |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 5.709 in |
| Mounting Bolt Hole Circle Diameter | 145 mm |
| Mounting Bolt Hole Diameter | 0.507 in |
| Mounting Bolt Hole Diameter | 12.9 mm |
| Mounting Bolt Hole Quantity | 8 |
| Nominal Thickness | 1.5 in |
| Nominal Thickness | 38.1 mm |
| Outside Diameter | 12.9 in |
| Outside Diameter | 327.65 mm |
| Overall Height | 4.875 in |
| Overall Height | 123.8 mm |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 8 |
Warranty Information
Manufacturer's Waranty
