Description
Product Attributes
| Center Hole Diameter | 3.55 in |
| Center Hole Diameter | 90.15 mm |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | No |
| Discard Thickness | 1.122 in |
| Discard Thickness | 28.5 mm |
| Inside Diameter | 8.543 in |
| Inside Diameter | 217 mm |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 5.315 in |
| Mounting Bolt Hole Circle Diameter | 135 mm |
| Mounting Bolt Hole Diameter | 0.605 in |
| Mounting Bolt Hole Diameter | 15.35 mm |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness | 1.181 in |
| Nominal Thickness | 30 mm |
| Outside Diameter | 12.992 in |
| Outside Diameter | 330 mm |
| Overall Height | 2.06 in |
| Overall Height | 52.3 mm |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 6 |
| Surface Type | Smooth |
Vehicle Linkages
-
Car/Truck
-
Ford
- F-150: 2009
-
Warranty Information
Manufacturer's Waranty
