Description
Product Attributes
| Center Hole Diameter | 3.545 in |
| Center Hole Diameter | 90.05 mm |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.26 in |
| Discard Thickness | 32 mm |
| Inside Diameter | 9.302 in |
| Inside Diameter | 236.25 mm |
| Mounting Bolt Hole Circle Diameter | 5.906 in |
| Mounting Bolt Hole Circle Diameter | 150 mm |
| Mounting Bolt Hole Diameter | 5.906 in |
| Mounting Bolt Hole Diameter | 150 mm |
| Mounting Bolt Hole Quantity | 7 |
| Nominal Thickness | 1.34 in |
| Nominal Thickness | 34.05 mm |
| Outside Diameter | 13.776 in |
| Outside Diameter | 349.9 mm |
| Overall Height | 1.949 in |
| Overall Height | 49.5 mm |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 7 |
| Surface Type | Smooth |
Vehicle Linkages
-
Car/Truck
-
Ford
- F-150: 2010 - 2014
- Lobo: 2012 - 2014
-
Warranty Information
Manufacturer's Waranty
