Product Description
Wagner® SD™ brake pads are specifically designed and tested to provide durable performance for fleets, police-pursuit and vehicles driven in demanding conditions such as frequent stopping, gear hauling and heavy loads.
UILT TOUGH -- Engineered for fleets and vehicles driven in demanding conditions
LONG LIFE -- Semi-metallic carbon-based friction material engineered in-house to deliver long lasting braking performance for the toughest applications
TESTED AND VALIDATED -- Rigorous OE-style on-vehicle testing to ensure optimal braking performance for vehicles under extreme heat, frequent stopping and heavy loads
OE DESIGN -- Features OE style shims, slots and chamfers
HARDWARE INCLUDED -- Premium stainless-steel hardware kits included for key applications
ZERO COPPER FORMULATION -- Features Wagner OE25™ zero-copper friction formulation
Disc Brake Pad Set Dimensions
Friction Material Composition
Semi-metallic
Pad Shims Included
Yes
FMSI Number
7699-D827
Inner Pad Friction Material Thickness (IN)
0.78
Outer Pad Friction Material Thickness (IN)
0.78
Slotted
Yes
Pad Wear Sensor Included
No
Abutment Clips Included
No
Chamfered Edges
No
Part Description
Disc Brake Pad Set
FMSI Steel
D827
FMSI Lining
7699
| Make | Model | Year Range | Description | Position | Veh. Qty. |
|---|---|---|---|---|---|
| Chevrolet | LCF 4500 | 2016-2017 | Disc Brake Pad Set | Front | 1 |
| Chevrolet | LCF 4500XD | 2017-2018 | Disc Brake Pad Set | Front | 1 |
| Chevrolet | LCF 5500HD | 2017-2018 | Disc Brake Pad Set | Front | 1 |
| Chevrolet | LCF 5500XD | 2017-2018 | Disc Brake Pad Set | Front | 1 |
| Chevrolet | W3500 Tiltmaster | 2001-2009 | Disc Brake Pad Set | Front | 1 |
| Chevrolet | W4500 Tiltmaster | 2000-2010 | Disc Brake Pad Set | Front | 1 |
| Chevrolet | W5500 Tiltmaster | 1999-2010 | Disc Brake Pad Set | Front | 1 |
| Chevrolet | W5500HD Tiltmaster | 2004-2009 | Disc Brake Pad Set | Front | 1 |
| GMC | W3500 Forward | 2001-2008 | Disc Brake Pad Set | Front | 1 |
| GMC | W4500 Forward | 1999-2010 | Disc Brake Pad Set | Front | 1 |
| GMC | W5500 Forward | 2010-2010 | Disc Brake Pad Set | Front | 1 |
| GMC | W5500 Forward | 1999-2009 | Disc Brake Pad Set | Front | 1 |
| GMC | W5500HD Forward | 2004-2009 | Disc Brake Pad Set | Front | 1 |
| Isuzu | NPR | 1999-2016 | Disc Brake Pad Set | Front | 1 |
| Isuzu | NPR-HD | 1999-2016 | Disc Brake Pad Set | Front | 1 |
| Isuzu | NQR | 1999-2016 | Disc Brake Pad Set | Front | 1 |
| Isuzu | NRR | 2005-2016 | Disc Brake Pad Set | Front | 1 |
