Product Description
NOTE: Due to size restrictions, brake drums are currently only available for pickup or via Truck Freight.
Webb 56864B CRT Vented Brake Drum 16.5 x 7 (3600X, 3922X) *Genuine Webb*
DRUM INFORMATION
Drum Part Number: 56864B
Weight: 104
Brake Shoe Width: 7
Back Plate Thickness: 0.48
Drum Type:
Mount: Outboard
Brake Surface Diameter: 16.50
Overall Depth: 10.52
Brake Surface Flat: 7.54
Pilot Diameter: 8.78
Bolt Circle Diameter: 11.25
Bolt Hole (Number): 10
Bolt Hole Size: 1.08
Maximum Wear Diameter: 16.62
Notes: Use 66884B for heavy duty applications.
Cross Reference
| Bluebird Bus | 43877 |
| Conmet | 10001776 |
| Conmet | 10001778 |
| Conmet | 10001800 |
| Conmet | 10009830 |
| Conmet | 107150 |
| Freightlliner | N42A1657VB |
| Gunite | 3570AX |
| Gunite | 3600A |
| Gunite | 3600AX |
| Gunite | 3922X |
| Mack | 3398-3922X |
| Meritor | 85-123207-002 |
| Paccar | 306613 |
| Peterbilt | 305449 |
| Peterbilt | 03-05449 |
| Webb | 66864 |
| Webb | 66864B |
| Webb | 66874 |
| Webb | 66874B |
