Description
Signal-Stat, Incandescent, 1"x2", Rectangular, Yellow, 1 Diode, White, 2 Screw Mount, Stripped End, Marker & Clearance Light
High-impact polycarbonate construction
Mini lamp features external mounting holes
Lens snaps and locks into base
Mounts without disassembly
Replaces Truck-Lite 26306 series
| Lighting Technology | Incandescent |
|---|---|
| Number of Diodes/Bulbs | 1 |
| Lens Shape | Rectangular |
| Lens Material | Polycarbonate |
| Lens Height_INH | 1 in |
| Lens Width_INH | 1.88 in |
| Common Size | 1"x2" |
| Total Height In INH | 1 |
| Total Width In INH | 3.18 |
| Total Depth In INH | 1.12 |
| Total Height In MMT | 25.4 mm |
| Total Depth In MMT | 28.45 |
| Total Width In MMT | 80.77 |
| Weight In LB | 0.08 |
| Mount Type | 2 Screw Mount |
| Mount/Trim Color | White |
| Mount/Trim Material | ABS |
| Housing Material | ABS |
| Lamp Connection | Hardwired |
| Plug Side One | Hardwired |
| Plug Side Two | Stripped End |
| Number of Wires | 1 |
| Voltage (VLT) | 12 |
| Compliance Family | P2 |
| Compliance Family | PC |
| Sealed/Bulb Replaceable | Bulb Replaceable |
| Product Group | Marker & Clearance Lighting |
| Series | Signal-Stat |
