Description
37 Series, Direct LED, 7", Round, Clear, 6 Diode, H4 - 3 blade connector, Headlight
Next Generation Optics Technology provides Best-in-Class beam pattern and increase light output where you need it
Rugged construction with miliary grade e-coat aluminum housing and polycarbonate lens for front-end protection
Options with Heated Technology, heat consistantely under 10 degrees C / 50 degrees F.
| Lighting Technology | Direct LED |
|---|---|
| Number of Diodes/Bulbs | 6 |
| Lens Color | Clear |
| Lens Shape | Round |
| Lens Material | Polycarbonate |
| Lens Height_INH | 1.2" in |
| Lens Width_INH | 7 in |
| Common Size | 7" |
| Total Height In INH | 7 |
| Total Width In INH | 7 |
| Weight In LB | 1.8 |
| Housing Material | Die-Cast Aluminum |
| Lamp Connection | Hardwired |
| Plug Side One | Hardwired |
| Plug Side Two | H4 - 3 blade connector |
| Number of Wires | 3 |
| Voltage (VLT) | 12 |
| Voltage (VLT) | 24 |
| Current Minor | 1.38A-1.98A @ 12.8V 0.70A-1.00A @ 25.8V |
| Sealed/Bulb Replaceable | Sealed |
| Product Group | Forward Lighting |
| Series | 37 Series |
