Description
Surface mount design eliminates the need for large hole cutouts in trailer ceiling
White housing design blends well with refrigerated trailer interiors
Available with integrated on/off switch as well as externally controlled version
Lens design recesses lens into housing, to prevent damage from impact
Not affected by cold temperatures, providing flicker-free lighting with a faster start-up time
Ideal for refrigerated vehicles or those operating in cold weather
Solid-state LED design is impervious to damage from shock and vibration
Retrofit or replacement is quick and easy
LEDs are fully encapsulated in epoxy to prevent damage caused by moisture and corrosives
Recommend 3 #10 machine screws for mounting, with torque of 15-18 in-lbs
| Lighting Technology | LED |
|---|---|
| Number of Diodes/Bulbs | 6 |
| Lens Color | Clear |
| Lens Shape | Round |
| Lens Material | Polycarbonate |
| Lens Height_INH | 4.25 in |
| Lens Width_INH | 4.25 in |
| Common Size | 4" |
| Total Height In INH | 5.9 |
| Total Width In INH | 5.9 |
| Total Depth In INH | 1.25 |
| Total Height In MMT | 149.86 mm |
| Total Width In MMT | 149.86 |
| Total Depth In MMT | 31.75 |
| Weight In LB | 0.49 |
| Mount Type | Flange Mount |
| Mount/Trim Color | White |
| Mount/Trim Material | Polycarbonate |
| Housing Material | Polycarbonate |
| Lamp Connection | Hardwired |
| Plug Side One | Hardwired |
| Plug Side Two | Stripped End |
| Number of Wires | 2 |
| Voltage (VLT) | 12 |
| Current_AMP | 0.54 |
| Sealed/Bulb Replaceable | Sealed |
| Product Group | Interior Utility & Dome Lighting |
| Series | Super 44 |
