Description
Engineered to feature ten bright and economical light emitting diodes (LEDs)
Uses standard PL-3 connector When properly mounted, exceeds FMVSS-P2 DOT requirements for marker/clearance performance Designed with impact-resistant acrylic material Sealed lens and housing locks moisture out Snap fit grommet requires no screws for installation LEDs do not have a filament, therefore are not susceptible to shock and vibration damage major cause of failure for lamps with an incandescent bulb
Epoxy-encapsulated electronics prevents damage from moisture and corrosion
Popular on owner/operator and show trucks
Lamps come with Truck-Lite 2-Year Limited Warranty
| Lighting Technology | LED |
|---|---|
| Number of Diodes/Bulbs | 10 |
| Lens Color | Red |
| Lens Shape | Round |
| Lens Material | Acrylic |
| Lens Height_INH | 4.27 in |
| Lens Width_INH | 4.27 in |
| Common Size | 4" |
| Total Height In INH | 4.28 |
| Total Width In INH | 4.28 |
| Total Depth In INH | 1.68 |
| Total Height In MMT | 108.71 mm |
| Total Width In MMT | 108.71 |
| Total Depth In MMT | 42.67 |
| Mount Type | Grommet Mount |
| Housing Material | Acrylic |
| Lamp Connection | PL-3 |
| Plug Side One | PL-3 |
| Plug Side Two | No Plug |
| Voltage (VLT) | 12 |
| Current Minor | 0.02 |
| Standards Met | P2 |
| Standards Met | I6 |
| Standards Met | S2 |
| Standards Met | T |
| Compliance Family | FMVSS 108 |
| Compliance Family | CMVSS 108 |
| Compliance Family | DOT |
| Compliance Family | SAE |
| Sealed/Bulb Replaceable | Sealed |
| Product Group | Stop Lighting |
