Description
1.25" Round P2/P3/PC2 Clearance Marker
The M09400 Series is a 1.25” grommet mounted red clearance marker lamp. With 6 LEDs behind a domed lens, it provides a wide 180-degree horizontal beam for maximum visibility. These 6 LEDs, combined with our patented Lightning Lens Optic, make it the brightest in the industry. It complies with P2 P3 and PC2 DOT requirements. It includes the mounting grommet which requires a 1-3/8" hole. This light features a polycarbonate lens & housing.
Features & Benefits:
- Includes Mounting Grommet
- Requires 1-3/8" Hole
- 180° Visibility - PC/PC2 Rated
- Patented Lightning Lens Optic
- US Patent No 8,009,364
- US Patent No 8,717,679 B2
- Also Available in Red Clear Lens (M09400RCL)
- Optional Steel Bezel (M50118)
- Polycarbonate Lens & Housing
Specifications:
- LEDs 6
- Voltage 12.8VDC
- Amp Draw 40mA
- Dimensions 1.25” Diam. x 1.0” H
- Mounting Grommet, 1-3/8” Hole
- Connector 2 Jacketed Leads, .180 Bullets, 7"
- Legal Heading P2 P3 PC2
- DOT/SAE J592 J2042
