Description
35 Series, LED, 1"x4", Rectangular, Red, 2 Diode, Red, 2 Screw Mount, P2
P3, Marker & Clearance Light
Complies with SAE J592 and J594 when mounted horizontally
Complies with SAE J592 when mounted horizontally between 0 degrees to 34 degrees rollback
OmniVolt Technology (12 or 24V systems will run without adjustment)
| Lighting Technology | LED |
|---|---|
| Number of Diodes/Bulbs | 2 |
| Lens Shape | Rectangular |
| Lens Material | Polycarbonate |
| Lens Height_INH | 0.75 in |
| Lens Width_INH | 4 in |
| Common Size | 1"x4" |
| Total Height In INH | 0.75 |
| Total Width In INH | 4 |
| Total Depth In INH | 1.25 |
| Total Height In MMT | 19.05 mm |
| Total Depth In MMT | 31.75 |
| Total Width In MMT | 101.6 |
| Weight In LB | 0.2 |
| Mount Type | 2 Screw Mount |
| Mount/Trim Color | Red |
| Housing Material | Polycarbonate |
| Lamp Connection | Fit 'N Forget M/C |
| Plug Side One | Fit 'N Forget M/C |
| Voltage (VLT) | 12 |
| Voltage (VLT) | 24 |
| Standards Met | P2 |
| Standards Met | P3 |
| Sealed/Bulb Replaceable | Sealed |
| Product Group | Marker & Clearance Lighting |
| Series | 35 Series |
