Description
Surface mounts on two screws at 15' centers
Ground-through base
Popular for use on school and commercial buses
Heavy-duty steel and acrylic construction
Lens attaches to base with one center screw
Optional zinc-plated steel guard provides additional protection
Replaces Signal-Stat 1151/1151A/9251
| Lighting Technology | Incandescent |
|---|---|
| Number of Diodes/Bulbs | 1 |
| Lens Shape | Rectangular |
| Lens Material | Acrylic |
| Common Size | - |
| Total Height In INH | 1.56 |
| Total Width In INH | 3.81 |
| Total Depth In INH | 1.81 |
| Total Height In MMT | 39.62 mm |
| Total Depth In MMT | 45.97 |
| Total Width In MMT | 96.77 |
| Mount Type | Bracket Mount Kit |
| Housing Material | Steel |
| Lamp Connection | Hardwired |
| Plug Side One | Hardwired |
| Plug Side Two | Stripped End |
| Number of Wires | 1 |
| Voltage (VLT) | 12 |
| Standards Met | P2 |
| Standards Met | PC |
| Sealed/Bulb Replaceable | Bulb Replaceable |
| Product Group | Marker & Clearance Lighting |
