Description
Our 36 Series Winged Flex-Lite is designed with a slim profile, winged housing for mounting option around corners on a radius combined with an adhesive backing for quick and easy installation, and PC Rated making this the most advanced, convenient, and compliant marker & clearance light available.
Winged housing provides option for mounting around corners on a radius
Provides a clearance/marker solution that requires no mounting brackets or installation screws
Lamps adhere directly to application surface through the use of heavy-duty adhesive backing
Easy-to-install peel-off liner
Hardwired lamp design is easily retrofit able
Rear exit wire version requires a 3/8mounting hole, and self-seals hole upon installation
Side mount options can be mounted without any mounting holes
LEDs draw much less current, allowing more power for other vehicle requirements
A PC rated legal lamp allows for one lamp instead of two to meet the 180 degrees
| Lighting Technology | LED |
|---|---|
| Number of Diodes/Bulbs | 3 |
| Lens Shape | Winged |
| Lens Material | Polycarbonate |
| Lens Height_INH | 0.56 in |
| Lens Width_INH | 1.36 in |
| Common Size | 1"x2" |
| Total Height In INH | 9.12 |
| Total Width In INH | 3.96 |
| Total Depth In INH | 0.75 |
| Total Height In MMT | 231.65 mm |
| Total Depth In MMT | 19.05 |
| Total Width In MMT | 100.58 |
| Weight In LB | 0.04 |
| Mount Type | Adhesive Mount |
| Mount Type | 2 Screw |
| Mount/Trim Color | Black |
| Mount/Trim Material | Polycarbonate |
| Housing Material | Polycarbonate |
| Lamp Connection | Hardwired |
| Plug Side One | Hardwired |
| Plug Side Two | .180 Bullet |
| Number of Wires | 2 |
| Voltage (VLT) | 12 |
| Compliance Family | P2 |
| Compliance Family | PC |
| Standards Met | P2 |
| Standards Met | PC |
| Sealed/Bulb Replaceable | Sealed |
| Product Group | Marker & Clearance Lighting |
| Series | 36 Series |
